The Vivotek IP7138 is a professional network camera with mega-pixel resolution for indoor surveillance applications and detail remote monitoring. Equipped with a 1.3 Mega-pixel (1280x1024) CMOS sensor delivering superior image details, it could be the best choice for monitoring extensive areas such as airports, factories, retail stores, schools, offices or banks. Embedded with Vivotek VVTK-1000 SoC, it enables to deliver dual streams with different resolutions and video quality upon different devices simultaneously such as PC (MPEG-4 or MJPEG), or 3G cell phone (MPEG-4 only). In addition, the Vivotek IP7138 builds in a compact flash card slot for local storage in case of connection failure. It also supports 3GPP mobile surveillance, which enables users to monitor via 3G cell phones or any RTSP (Real Time Streaming Protocol) compatible multimedia device on the go. More features are enhanced in the Vivotek IP7138 to meet specific applications such as two-way audio, digital I/O interface, built-in 802.3af compliant PoE, and appropriate lens selection with CS mount. With its versatile functions, the Vivotek IP7138 provides a total solution for customers' diverse needs.
Manufacturer:
Vivotek, Inc
Manufacturer Part Number:
IP7138
Manufacturer Website Address:
www.vivotek.com
Brand Name:
Vivotek
Product Model:
IP7138
Product Name:
IP7138 Mega-Pixel PoE Network Camera
Product Type:
Surveillance/Network Camera
Lens Type:
Focal Length: 4mm
Connectivity Technology:
Cable
Protocols:
RTSP
Interfaces/Ports:
1 x Microphone
Package Contents:
IP7138 Mega-Pixel PoE Network Camera
Power Adapter
Camera Mount Kit & Pads
Warranty Card
Software CD
Quick Guide
Additional Information:
Features:
Appropriate Lens Selection with CS Mount
Built-in CF Card Slot for Local Storage ( CF Card support list )
MPEG-4 and MJPEG Video Compression (Dual Codec)
Supports Simultaneous Dual Streams (RTSP Streaming for MPEG-4 Mode with Resolution up to 800x600; Server Push for MJPEG Mode with Resolution up to 1280x1024)
Supports 3GPP Mobile Surveillance
Supports Two-way Audio
Built-in 802.3af Compliant PoE (Power over Ethernet)
One D/I and One D/O for Sensor and Alarm
Supports Privacy Masks
System Requirements:
Viewing System Requirements:
OS: Microsoft Windows 2000, XP
Browser: Internet Explorer 5.x or above
Cell Phone: 3GPP player
Real Player 10.5
Quick Time 6.5
Packet Video Player 3.0
Security Features:
Multi-level user access
IP address filtering
Platform Support:
PC
