Netgear ProSafe JFS516 Ethernet Switch

Computer > Enterprise Computing > Network Switches

Left Side Pixel
JFS516NA - Netgear ProSafe JFS516 Ethernet Switch
Netgear ProSafe JFS516 Ethernet Switch
Bookmark and Share
NETGEAR
Price: $75.99
Availability: 453 In Stock
Mfg Part# JFS516NA
Quantity:

HACKER SAFE certified sites prevent over 99.9% of hacker crime.
BBB.org
Right Side Pixel
Bottom Pixel
Advertisement
NETGEAR presents a great way to increase your network's capability without breaking your budget: the 16-port JFS516. This 10/100 Fast Ethernet switch provides expanded connectivity for small office networks so users no longer have to compete with each other for bandwidth. All of the essential features automatic speed and full/half duplex sensing, 200 Mbps throughput per port, Auto Uplink are included, but at an economical price that a value-conscious business owner can't ignore. Thrifty: The ideal, low-cost solution you've been looking for, the unmanaged JFS516 lets you ramp up your office network to a new power level affordably. Capable: Sixteen switched ports provide private bandwidth for PCs, servers, or hubs, and support 200 Mbps of throughput. Each port delivers 200 Mbps of network speed in full-duplex mode. Perceptive: As soon as it's powered on, it begins operating. Every port automatically senses the proper speed and full/half duplex mode, and Auto Uplink adjusts for straight-through or crossover cables to make the right link. Practical: This high-performance switch makes it easy to combine 10 and 100 Mbps devices within your network. As an added convenience, these sturdy metal units can be mounted in a standard 19-inch rack.

General Information
  • Manufacturer:
    Netgear, Inc
  • Manufacturer Part Number:
    JFS516NA
  • Manufacturer Website Address:
    www.netgear.com
  • Brand Name:
    Netgear
  • Product Line:
    ProSafe
  • Product Model:
    JFS516
  • Product Name:
    ProSafe JFS516 Ethernet Switch
  • Product Type:
    Ethernet Switch
Interfaces/Ports
  • Number of Ports:
    16
  • Fast Ethernet Port:
    Yes
  • Interfaces/Ports:
    16 x RJ-45 10/100Base-TX LAN
Media & Performance
  • Connectivity Media:
    Twisted Pair 10/100Base-TX
  • Forwarding/Filtering Rate:
    148 Kpps
  • Performance:
    14800Mbps Forwarding Rate For 64-byte Packet 10Mbps Port
Network & Communication
  • Address Table:
    4 K MAC Address -
Controls/Indicators
  • Status Indicators:
    Unit: Power Per network port: 10 or 100 Mbps operations, Rx/Tx and collision, link, half/full duplex
Power Description
  • Input Voltage:
    220 V AC
  • Input Voltage Range:
    100 V AC to 240 V AC
  • Frequency:
    50 Hz or 60 Hz
  • Power Consumption:
    Up to 15 W @
Environmental Conditions
  • Temperature:
    32 F (0 C) to 104 F (40 C) Operating
  • Humidity:
    0% to 80% Non-condensing Relative Humidity Operating
Physical Characteristics
  • Color:
    Blue
  • Height:
    1.7"
  • Width:
    13"
  • Depth:
    8"
  • Weight (Approximate):
    4.40 lb
Miscellaneous
  • Package Contents:
    JFS516 Ethernet Switch Power cord Rack-mount kit User guide Warranty card Support card
  • Additional Information:
    Plug and Play Auto-detects speed and duplex Auto Uplink Technology makes the right connection Half-duplex, Full-duplex Store-and-forward packet switching Latency (10 to 100 Mbps) 20 usec max
  • Certifications & Standards:
    IEEE 802.3i 10BASE-T Ethernet IEEE 802.3u 100BASE-TX Fast Ethernet Electromagnetic Emissions: CE mark, commercial FCC Part 15 Class A EN 55 022 (CISPR 22), Class A VCCI Class A C-Tick MIC Safty Agency Approvals: UL listed (UL 1950)/CUL TUV licensed (EN 60 950)
Warranty
  • Standard Warranty:
    Lifetime
