EnGenius EOA7535 Wireless Bridge

Electronics > Cell Phones & Accessories > Cell Phones & Devices

EOA7535 - EnGenius EOA7535 IEEE 802.11a/b/g 54 Mbps Wireless Bridge

ENGENIUS TECHNOLOGIES

Price: $364.99

Availability: 1 In Stock

Mfg Part# EOA7535

Quantity:

EOA7535 equips with two powerful independent RF radios which support 802.11a and 802.11b/g. With industrial IP-68 rugged enclosure, RF Lightning Protector & Ethernet Surge Arrestor, it is designed to deliver the highest performance and reliability under harsh outdoor environment.Unique multi-function capability provides flexibility in constructing scalable WiFi networks for any possible applications. With two individual radios, each can be configured as 3 different operation modes with maximum of 5 combinations. EOA7535 offers wireless bandwidth up to 54Mbps to accommodate busy traffic services such as file transfers or Internet data uploads and downloads. EOA7535 is the ideal outdoor repeater where it uses 802.11a for long-range backbone network while rebroadcasts wireless signal for client access via 802.11b/g.

General Information

Manufacturer:
EnGenius Technologies, Inc
Manufacturer Part Number:
EOA7535
Manufacturer Website Address:
www.engeniustech.com
Brand Name:
EnGenius
Product Model:
EOA7535
Product Name:
EOA7535 Wireless Bridge
Product Type:
Wireless Bridge

Technical Information

Wi-Fi Standard:
IEEE 802.11a/b/g
ISM Band:
Yes
UNII Band:
Yes
ISM Minimum Frequency:
2.40 GHz
ISM Maximum Frequency:
2.48 GHz
UNII Minimum Frequency:
5.15 GHz
UNII Maximum Frequency:
5.83 GHz
Number of Antennas:
2
Antenna Gain:
5 dBi
Antenna Type:
Omnidirectional Antenna
Antenna Connector:
N-type
Wireless Transmission Speed:
54 Mbps
Wireless Security:
WPA WPA2 TKIP AES IEEE 802.1X EAP-TLS TTLS MAC address access control list MAC address Filtering NAT WPA-PSK WPA2-PSK 64/128/152-bit WEP IEEE 802.1x PPTP

Interfaces/Ports

Gigabit Ethernet Port:
Yes
Number of Network (RJ-45) Ports:
1

Management & Protocols

Management:
VLAN Quality of Service DHCP Web-based configuration Telnet SNMP V1 , V2c

Power Description

Power Over Ethernet:
Yes
Input Voltage:
48 V DC
Power Source:
Power Supply

Physical Characteristics

Form Factor:
Mast-mountable
Height:
3.0"
Depth:
9.7"
Weight (Approximate):
3.02 lb

Miscellaneous

Package Contents:
EOA7535 Wireless Bridge 1 x 48V/0.375A Power Adapter 1 x Mounting kit 1 x QIG 1 x CD (User Manual) 2 x Dipole Antennas
Green Compliant:
Yes
Green Compliance Certificate/Authority:
WEEE
