Allied Telesis AT-MC100 Media Converter

Call us at 888-566-NERD(6373)

Home

Your Account

Help

Your Cart: 120 Item(s): $36976.94 View Cart

Home > Computer > Enterprise Computing > Network Transceivers

ALLIED TELESYN

Price: $176.99

Availability: 222 In Stock

Mfg Part# ATMC102XL10

Quantity:

Limited Exchanges

Product Information

When connecting media converter to auto-negotiating Fast Ethernet switches, this media converter will automatically connect the link in either Full or Half-Duplex mode, allowing the link to be established with the greatest bandwidth. Alternatively, the MissingLink feature allows accurate reporting to network management systems as well as allowing devices with redundant link capability to be inter-connected with these media converters, as a failure in one fiber link will be signalled to the switch, allowing the second link to become active.

General Information

Manufacturer:
Allied Telesis, Inc
Manufacturer Part Number:
AT-MC102XL-10
Manufacturer Website Address:
www.alliedtelesis.com
Brand Name:
Allied Telesis
Product Series:
AT-MC100
Product Name:
AT-MC100 Media Converter
Product Type:
Media Converter

Interfaces/Ports

Number of Ports:
2
Interfaces/Ports:
1 x RJ-45

Media & Performance

Connectivity:
UTP
Connectivity Media:
100Base-TX UTP
Distance Support:
1.24Mile

Network & Communication

Network Technology:
100Base-FX

Management & Protocols

Protocols:
Fast Ethernet

Controls/Indicators

Status Indicators:
Front Panel:Power: Indicates power is applied to the converterLink (2): Indicates a valid receive link existsReceive (2): Indicates valid data being received by converterNormal/Test: Fiber test or normal operation

Power Description

Input Voltage:
12 V DC 5%
Power Consumption:
6 W Operating

Environmental Conditions

Temperature:
32 F (0.0 C) to 104 F (40.0 C) Operating
Humidity:
5 to 95% Operating
Altitude:
0 ft to 10000 ft Operating

Physical Characteristics

Color:
White
Dimensions:
1" Height x 4.12" Width x 3.75" Depth
Shipping Dimensions:
3" Height x 5.8" Width x 11.25" Depth
Weight:
0.65 lb
Shipping Weight:
2.42 lb

Miscellaneous

Additional Information:
Half and Full Duplex operationTransparent to 802.1Q packetsFits the AT-MCR12 rackmount chassisMDI/MDIXMissingLinkLink Test External Power Supply:100-240vAC, 50/60Hz +/- 3% PACKET TRANSMISSION CHARACTERISTICS:Round Trip Delay: 0.4us MaximumBit Error Rate (BER): < 10 -12 TWISTED PAIR INTERFACE: UTP Differential Output Voltage: - Typical: 980mv - Min: 950mv - Max: 1050mv Overshoot Voltage: - Typical: 4% - Max: 5% Single Amplitude Symmetry: - Typical: 1.0062 - Min: 0.98 - Max: 1.02 Rise and Fall Time: - Rise: - Typical: 4.6ns - Min: 3.0ns - Max: 5.0ns - Fall: - Typical: 4.2ns - Min: 3.0ns - Max: 5.0ns Rise and Fall Time Symmetry: - Typical: 0.4ns - Max: 0.5ns Port Type (Connector): 100FX MMF: - Launch Power (dBm): - Max: -14.0 - Avg: -16.8 - Min: -19.0 - Receive Power (dBm): - Min. Sensitivity: -31.8 - Typical Sensitivity: -34.5 - Saturation: -14.0
Certifications & Standards:
IEEE 802.3U-LAN EMC:FCC Class A Safety:UL-CulCSA/CSANRTLTUVCE

Warranty
